Using the machine
M20 JEWEL: Choose jewelry jigs or plastic jigs according to the object to be engraved and the length of the
plate.
Jewelry jigs Plastic jigs
2. Choose the appropriate side of the jig according to the object to be engraved or the thickness of
the plate.
Theplatemustbeslightlyhigherthanthejigsinordertopreventtheregulatingnosefromstrikingthejig:
Jig(s)
M20 JEWEL: To engrave a chain bracelet, place the chain bracelet protection on the vice.
1
2
1. Chain protection tray - bracelets
2. Jewelry jigs
