Using the machine
• Theinputscanactivatevariousfunctionsaccordingtotheircon󰘰guration:
Function Description
1
Startmarking
2 Pause
3 Return to origin (0,0)
• Theoutputscanbeactivatedaccordingtotheircon󰘰guration:
Function Description
1 Spindle in operation
2 Machine paused
3 Machine at the origin (0,0)
4 Tool in the lowered position (in the material)
10 Spindle stopped
Example:
OUT1 = 2: The 1 (Pin 1) output is activated when the machine is paused.
IN2 = 3: The machine returns to the origin when the input 2 (Pin 14) receives a pulse.
