Adaptable accessories
1. Tailstock
2. Thumbwheel
3. Lockingscrew
1
2
3
3. Hold the object horizontally and slide the tailstock by pressing the locking button.
Engagetheobjectsuchthatitisheldsecurelybytheconeorthetailstock.
4. Lock the tailstock mount by releasing the locking button.
5. Adjust the clamping with the thumb wheel if necessary.
6. Launch the marking cycle.
