Grizzly G0824 User Manual

-102-
Model G0824 (Mfd. Since 12/16)
Apron Parts
REF PART # DESCRIPTION REF PART # DESCRIPTION
401 P08240401 GEAR 60T 442 P08240442 OIL SIGHT GLASS M20-2.5
402 P08240402 ROLL PIN 5 X 30 443 P08240443 ROLL PIN 5 X 35
403 P08240403 GEAR 18T W/COLLAR 444 P08240444 COMPRESSION SPRING
404 P08240404 PINION GEAR 13T 445 P08240445 STEEL BALL 3/16
405 P08240405 SET SCREW M6-1 X 16 446 P08240446 APRON GEARBOX PLUG (L)
406 P08240406 BUSHING 447 P08240447 ROLL PIN 3 X 25
407 P08240407 CAP SCREW M6-1 X 12 448 P08240448 DOWEL PIN 5 X 25
408 P08240408 FLAT WASHER 6MM 449 P08240449 SET SCREW M6-1 X 6
409 P08240409 GEAR 18T 450 P08240450 LEVER HUB
410 P08240410 IDLER SHAFT 451 P08240451 LEVER HANDLE M8-1.25 X 10, 90L
411 P08240411 CAP SCREW M5-.8 X 12 452 P08240452 SPACER
412 P08240412 O-RING 20 X 2.4 453 P08240453 FRONT COVER
413 P08240413 SHAFT 454 P08240454 FEED DIRECTION INDICATOR
414 P08240414 WORM GEAR 455 P08240455 TAPER PIN 5 X 20
415 P08240415 FLAT WASHER 6MM 456 P08240456 FEED SELECTION CAM SHAFT
416 P08240416 CAP SCREW M6-1 X 12 457 P08240457 LEVER HANDLE M8-1.25 X 33 ROUND TIP, 90L
417 P08240417 INTERLOCK BAR 458 P08240458 COMPRESSION SPRING
418 P08240418 CAP SCREW M6-1 X 12 459 P08240459 CAM SHAFT BRACKET
419 P08240419 SET SCREW M6-1 X 12 460 P08240460 CAP SCREW M6-1 X 35
420 P08240420 HEX BOLT M5-.8 X 20 461 P08240461 FEED SELECTION BRACKET PLUG
421 P08240421 HALF-NUT GIB 462 P08240462 TOOTHED SHIFT SHAFT
422 P08240422 HEX BOLT M6-1 X 10 463 P08240463 CAP SCREW M6-1 X 16
423 P08240423 SET SCREW M6-1 X 35 464 P08240464 CLUTCH GEAR 63T
424 P08240424 HEX NUT M6-1 465 P08240465 CLUTCH GEAR 40T
425 P08240425 THREAD DIAL INDICATOR 466 P08240466 COMBO CLUTCH GEAR 30T
425-1 P08240425-1 THREAD DIAL LABEL 467 P08240467 APRON GEARBOX PLUG (R)
426 P08240426 HALF-NUT BRACKET 468 P08240468 BALL OILER 8MM TAP-IN
427 P08240427 HALF-NUT ASSEMBLY 469 P08240469 SHLDR SCR M8-1.25 X 12, 10 X 66
428 P08240428 DOWEL PIN 8 X 16 470 P08240470 HANDWHEEL HANDLE 22 X 75 X 10
429 P08240429 WORM GEAR 470A P08240470A HANDLE 22 X 75 X 10 W/SCREW
430 P08240430 CAM SHAFT 471 P08240471 FLAT HD SCR M6-1 X 16
431 P08240431 SET SCREW M5-.8 X 16 472 P08240472 FLAT WASHER 6MM
432 P08240432 HEX NUT M5-.8 473 P08240473 HANDWHEEL TYPE-4 140D X 16B-K
433 P08240433 CAP SCREW M8-1.25 X 50 474 P08240474 GRADUATED DIAL
434 P08240434 THREAD DIAL BODY 475 P08240475 CAP SCREW M5-.8 X 25
435 P08240435 HELICAL GEAR 32T 476 P08240476 HANDWHEEL SUPPORT HUB
436 P08240436 FLAT WASHER 8MM 477 P08240477 SPACER
437 P08240437 HEX NUT M8-1.25 478 P08240478 KEY 5 X 5 X 20
438 P08240438 RIVET 3 X 5MM NAMEPLATE 479 P08240479 GEARED SHAFT 14T
439 P08240439 THREAD DIAL CHART 480 P08240480 CAP SCREW M8-1.25 X 30
440 P08240440 DRAIN PLUG 1/8 NPT 481 P08240481 TAPER PIN 8 X 40
441 P08240441 HALF-NUT INDICATOR PLATE
