Model G0824 (Mfd. Since 12/16)
-25-
4. Make sure wires have enough slack between
strain relief and terminal connections so they
are not pulled tight or stretched, then tighten
strain relief to secure cord.
Note: The strain relief must be tightened
against the outer jacket of the cord. Avoid
over-tightening the strain relief or it may
crush the cord and cause a short.
5. Test the strain relief to ensure it is properly
tightened by pulling the cord from outside the
box with light-to-moderate force. When strain
relief is properly tightened, cord will not move
inside cabinet.
6.
Install a NEMA 6-15 plug on the other end
of the power cord per plug manufacturer's
instructions.
7. Re-install main electrical box cover.
8.
Plug cord into matching power supply recep-
tacle and power source as specified in Circuit
Requirements for 220V on Page 14.
To avoid unexpected start-up, keep the
RESET button pressed in until instructed
otherwise in the Test Run.
Test Run
Once assembly is complete, test run the machine
to ensure it is properly connected to power and
safety components are functioning correctly.
If you find an unusual problem during the test run,
immediately stop the machine, disconnect it from
power, and fix the problem BEFORE operating the
machine again. The
Troubleshooting
table in the
SERVICE section of this manual can help.
DO NOT start machine until all preceding
setup instructions have been performed.
Operating an improperly set up machine
may result in malfunction or unexpect-
ed results that can lead to serious injury,
death, or machine/property damage.
Serious injury or death can result from
using this machine BEFORE understanding
its controls and related safety information.
DO NOT operate, or allow others to operate,
machine until the information is understood.
The test run consists of verifying the following:
• Motor powers up and runs correctly
• Emergency Stop/RESET button works
correctly.
• Brake system works correctly
• Lamp works correctly
• Coolant system works correctly
• Jog button works correctly
To test run machine:
1
. Clear away all tools and objects used during
assembly, lubrication, and preparation.
2
. Secure chuck and jaws, if installed (refer to
Chuck Installation on Page 30).
Note: If a chuck is not installed on the lathe,
you do not need to install one for this test.
