Grizzly G0824 User Manual

Model G0824 (Mfd. Since 12/16)
-91-
Control Panel Wiring
Figure 150. Control panel wiring.
Power
Light
STOP/Reset
Switch
Pump
Switch
Jog Button
ON Button
NO
C
NC
NO
NC
C
Ground
Spindle Rotation Switch
Quick-Change Gearbox
ON Button
Ground
Power Light
STOP/Reset
Switch
Pump Switch
Jog Button
Control
Panel
0
0 3
2
2
2
2
2
2
9
4
1
5
6
Headstock
H
I
