Grizzly G0824 User Manual

Model G0824 (Mfd. Since 12/16)
-113 -
Main Electrical Breakdown
14NO 24NO 34NO 44NO
13NO 23NO 33NO 43NC
KA1
Contactor
Tianshui
JZC3-14D
A1
A2
A2
14NO 24NO 34NO 44NO
13NO 23NO 33NO 43NC
KA0
Contactor
Tianshui
JZC3-14D
A1
A2
A2
2 T1 4 T2 6 T3 22NC
1 L1 3 L2 5 L3 21NC
KM1
Contactor
Tianshui
GSC1-1801
A1
A2
A2
2 T1 4 T2 6 T3 22NC
1 L1 3 L2 5 L3 21NC
KM2
Contactor
Tianshui
GSC1-1801
A1
A2
A2
2T1 6T34T2
NA NC
1L1 5L33L3
98 97 95 96
2T1 6T34T2
NA NC
1L1 5L33L3
98 97 95 96
FR1
FR2
20212223242526
E
33323130
Transformer
TC
ON
OFF
QM1
ON
OFF
QM2
1201
1202
1203
1204
1205
1221
1206
1223
1207
1208
1209
1210
1211
1212
1213
1214
1215
1216
1217
1218
1219
1220
1222
1225
1224
REF PART # DESCRIPTION REF PART # DESCRIPTION
1201 P08241201 TRANSFORMER WUXI JBK5-120VATH 1214 P08241214 BUTTON SWITCH HUILONG LA103 GREEN 22MM
1202 P08241202 CIRCUIT BREAKER TIAN DZ451-63 3A 1215 P08241215 ROTARY SWITCH HUILONG LA103 ON/OFF 22MM
1203 P08241203 CIRCUIT BREAKER TIAN DZ451-63 5A 1216 P08241216 E-STOP BUTTON HUILONG LA103 22MM
1204 P08241204 OL RELAY TIAN JRS4-09/40D 9-13A 1217 P08241217 JOG BUTTON HUILONG LA103 10A 22MM
1205 P08241205 OL RELAY TIAN JRS4-09/40D 0.4-0.63A 1218 P08241218 WORK LAMP ASSEMBLY
1206 P08241206 CONTACTOR TIAN JZC3-40D 110V 1219 P08241219 LAMP LENS
1207 P08241207 CONTROL PANEL PLATE 1220 P08241220 LED BULB 50W 24V
1208 P08241208 COPPER GROUND BLOCK 1221 P08241221 CONTACTOR TIANSHUI GSC1-1801 110V
1209 P08241209 TERMINAL BAR 12P 1222 P08241222 STRAIN RELIEF TYPE-3 M16-1.5 ST PLASTIC
1210 P08241210 TERMINAL BAR 28P 1223 P08241223 STRAIN RELIEF TYPE-7 1/4 ST METAL
1211 P08241211 ELECTRICAL BOX ASSEMBLY 1224 P08241224 PHLP HD SCR M5-.8 X 6
1212 P08241212 STRAIN RELIEF TYPE-3 M20-1.5 ST PLASTIC 1225 P08241225 ELECTRICAL BOX COVER
1213 P08241213 INDICATOR LIGHT X01013 GREEN
