Grizzly G0824 User Manual

Model G0824 (Mfd. Since 12/16)
-17-
Figure 9. Mounted inventory components.
A
B
D
Figure 10. Loose inventory components.
H
F
I
G
E
K
T
U
S
YX
W
V
Z
AA
AB
AC
Figure 11. Toolbox inventory.
L
R
Q
P
O
N
M
J
Inventory
The following is a list of items shipped with your
machine. Before beginning setup, lay these items
out and inventory them.
If any non-proprietary parts are missing (e.g. a
nut or a washer), we will gladly replace them; or
for the sake of expediency, replacements can be
obtained at your local hardware store.
Mounted Inventory Components Qty
A. Three-Jaw Universal Chuck 7" ................... 1
B.
Quick-Change Tool Post w/Holder ............. 1
C.
Follow Rest ................................................. 1
D .
Steady Rest ................................................ 1
Loose Inventory Components Qty
E. DRO Unit .................................................... 1
F.
Toolbox ....................................................... 1
G
. Faceplate 11" .............................................. 1
H.
Four-Jaw Chuck 8" ..................................... 1
I.
Camlock Studs (Installed) .......................... 6
J.
Cap Screws M6-1 x 14 (Installed) .............. 6
K.
Four-Jaw Chuck Wrench ............................ 1
Toolbox Inventory Components Qty
L. Bottle for Oil ............................................... 1
M
. Three-Jaw Chuck Key ................................ 1
N.
Drill Chuck B16 1.6-13mm .......................... 1
O.
Arbor B16 x MT#3....................................... 1
P.
Drill Chuck Key ........................................... 1
Q.
Spindle Wrench .......................................... 1
R.
End Gears 30T (Installed), 40T, 44T, 46T,
52T, 54T, 56T, 57T, 63T
......................1 Ea.
S.
End Gears 60T (One Installed) .................. 2
T.
Open-End Wrench Set
10/12, 12/14, 17/19mm ..........................1 Ea.
U.
Hex Wrenches 2, 2.5, 3, 4, 5, 6, 8mm .1 Ea.
V.
Tapered Spindle Sleeve MT#6 x MT#3 ...... 1
W.
Flat Head Screwdriver 3" ............................ 1
X.
Phillips Screwdriver 3" ................................ 1
Y.
Spider Screw w/Nuts .................................. 8
Z.
Dead Center MT#3 Carbide Tip ................. 1
AA.
Dead Center MT#3 HSS Tip ...................... 1
AB.
Handwheel Handles ................................... 2
AC.
Tool Holder (One Installed) ........................ 2
AD.
End Gear 120/127T (Installed) ................... 1
C
