Model G0824 (Mfd. Since 12/16)

Cabinet & Brake Parts

REF PART # DESCRIPTION REF PART # DESCRIPTION

1101 P08241101 BACK SPLASH 1117 P08241117 CLEVIS PIN

1102 P08241102 PHLP HD SCR M6-1 X 10 1118 P08241118 ROLL PIN 3 X 25

1103 P08241103 CAP SCREW M6-1 X 20 1119 P08241119 BRAKE PEDAL SHAFT (SHORT)

1104 P08241104 FLAT WASHER 6MM 1120 P08241120 SET SCREW M8-1.25 X 6

1105 P08241105 COTTER PIN 2 X 12 1121 P08241121 HEX NUT M8-1.25

1106 P08241106 CLEVIS PIN 1122 P08241122 ROLL PIN 5 X 40

1107 P08241107 BASE PAN 1123 P08241123 BRAKE PEDAL SHAFT (LONG)

1108 P08241108 ACCESS PLATE (REAR) 1124 P08241124 BRAKE PEDAL

1109 P08241109 BRAKE PULL ROD 1125 P08241125 HEX NUT M6-1

1110 P08241110 PEDESTAL (LEFT) 1126 P08241126 CAP SCREW M12-1.75 X 50

1111 P08241111 PEDESTAL (RIGHT) 1127 P08241127 CAP SCREW M6-1 X 10

1112 P08241112 COVER (LIFT ACCESS) 1128 P08241128 CHIP DRAWER

1113 P08241113 LEFT CABINET COVER (SIDE) 1129 P08241129 STAND PLATE BRACKET (LEFT)

1114 P08241114 HEX BOLT M8-1.25 X 40 1130 P08241130 LIMIT SWITCH SHANGHAI MACHINE LXW5

1115 P08241115 EXTENSION SPRING 1131 P08241131 STAND PLATE

1116 P08241116 PEDAL ARM 1132 P08241132 STAND PLATE BRACKET (RIGHT)
