-104-

Model G0824 (Mfd. Since 12/16)

Cross Slide Parts

REF PART # DESCRIPTION REF PART # DESCRIPTION

501 P08240501 SLIDE NUT M8-1.25 523 P08240523 CROSS SLIDE LEADSCREW HUB

502 P08240502 COMPOUND REST AXIS 524 P08240524 CAP SCREW M6-1 X 25

503 P08240503 CAP SCREW M6-1 X 16 525 P08240525 COVER PLATE

504 P08240504 BUSHING 526 P08240526 CAP SCREW M8-1.25 X 12

505 P08240505 BALL OILER 8MM TAP-IN 527 P08240527 CAP SCREW M8-1.25 X 20

506 P08240506 CROSS SLIDE 528 P08240528 GIB SLIDE (FRONT LEFT)

507 P08240507 GIB ADJUSTING SCREW 529 P08240529 GIB SLIDE (FRONT RIGHT)

508 P08240508 CROSS-SLIDE GIB 530 P08240530 V-WIPER

509 P08240509 ROLL PIN 3 X 16 531 P08240531 V-WIPER SUPPORT PLATE

510 P08240510 CROSS-SLIDE LEADSCREW 532 P08240532 PHLP HD SCR M4-.7 X 12

511 P08240511 SET SCREW M6-1 X 25 533 P08240533 HEX NUT M6-1

512 P08240512 SET SCREW M8-1.25 X 10 534 P08240534 CAP SCREW M8-1.25 X 25

513 P08240513 CAP SCREW M6-1 X 16 535 P08240535 GIB SUPPORT

514 P08240514 HANDWHEEL 86MM D 536 P08240536 SADDLE GIB

515 P08240515 GRADUATED DIAL 537 P08240537 FLAT WIPER SUPPORT PLATE

516 P08240516 BEARING COVER 538 P08240538 FLAT WIPER

517 P08240517 THRUST BEARING 8102 539 P08240539 CROSS-SLIDE LEADSCREW NUT

518 P08240518 GEAR 19T 540 P08240540 STEEL BALL 6MM

519 P08240519 HANDWHEEL HANDLE 22 X 75 X 10 541 P08240541 COMPRESSION SPRING

519A P08240519A HANDLE 22 X 75 X 10 W/SCREW 542 P08240542 BACKLASH ADJUSTMENT DISC

520 P08240520 SHLDR SCR M8-1.25 X 12, 10 X 66 543 P08240543 SET SCREW M6-1 X 25

521 P08240521 SADDLE CASTING 544 P08240544 CAP SCREW M8-1.25 X 55

522 P08240522 PHLP HD SCR M5-.8 X 10
