Model G0824 (Mfd. Since 12/16)
Motor & Feed Rod Parts
REF PART # DESCRIPTION REF PART # DESCRIPTION
1001 P08241001 V-BELT GATES V13 X 920 1031 P08241031 SHOULDER FLANGE SCREW
1002 P08241002 SET SCREW M6-1 X 12 1032 P08241032 SET SCREW M6-1 X 20
1003 P08241003 KEY 8 X 8 X 40 1033 P08241033 FEED ROD END PLUG
1004 P08241004 LOCK WASHER 8MM 1034 P08241034 CONTROL ROD END PLUG
1005 P08241005 HEX BOLT M8-1.25 X 25 1035 P08241035 BALL OILER 6MM TAP-IN
1006 P08241006 MOTOR 2.5HP 220V 1-PH 1036 P08241036 CAP SCREW M8-1.25 X 60
1006-1 P08241006-1 FAN COVER 1037 P08241037 TAPER PIN 5 X 60
1006-2 P08241006-2 MOTOR FAN 1038 P08241038 LOCK COLLAR
1006-3 P08241006-3 S CAPACITOR 150M 250V 1-3/8 X 2-3/4 1039 P08241039 SET SCREW M6-1 X 8
1006-4 P08241006-4 R CAPACITOR 20M 450V 1-5/8 X 2-3/4 1040 P08241040 LOCKING BEARING COVER
1006-5 P08241006-5 CAPACITOR BOX COVER 1041 P08241041 SET SCREW M8-1.25 X 10
1006-6 P08241006-6 CONTACT PLATE 1042 P08241042 FEED ROD
1006-7 P08241006-7 CENTRIFUGAL SWITCH 1043 P08241043 INDEX LUG PIN
1006-8 P08241006-8 BALL BEARING 60205ZZ (FRONT) 1044 P08241044 SET SCREW M8-1.25 X 16
1006-9 P08241006-9 BALL BEARING 60205ZZ (REAR) 1045 P08241045 LOCK COLLAR
1007 P08241007 KNURLED KNOB M8-1.25, 16 X 25 1046 P08241046 SPINDLE ON/OFF LEVER
1008 P08241008 MOTOR PULLEY 1047 P08241047 BALL KNOB M10-1.5 PLASTIC
1009 P08241009 MOTOR MOUNT 1048 P08241048 SPINDLE ON/OFF SWITCH ASSY
1010 P08241010 HEX BOLT M10-1.5 X 30 1049 P08241049 ROD HOUSING
1011 P08241011 ROLL PIN 6 X 25 1050 P08241050 COMPRESSION SPRING
1012 P08241012 FLAT WASHER 10MM 1051 P08241051 THRUST WASHER
1013 P08241013 CAP SCREW M6-1 X 25 1052 P08241052 KEY 4 X 4 X 40
1014 P08241014 GAP RACK 1053 P08241053 FLANGED SLEEVE
1015 P08241015 GAP INSERT 1054 P08241054 CONTROL ROD
1016 P08241016 CAP SCREW M10-1.5 X 40 1055 P08241055 SET SCREW M4-.7 X 4.5 CONE-PT
1017 P08241017 TAPER PIN 8 X 60 1056 P08241056 FLAT HD SCR M4-.7 X 6
1018 P08241018 STANDOFF HEX M8-1.25 X 11 X 20, 100L 1057 P08241057 CLUTCH ASSEMBLY
1019 P08241019 GEAR COVER 1058 P08241058 COMPRESSION SPRING
1020 P08241020 LATHE BED 1059 P08241059 STEEL BALL 6MM
1021 P08241021 KNURLED THUMB KNOB M10-1.5 1060 P08241060 SHEAR PIN
1022 P08241022 RACK 1061 P08241061 SHUT-OFF SUPPORT
1023 P08241023 HEX NUT M8-1.25 1062 P08241062 PHLP HD SCR M5-.8 X 8
1024 P08241024 STANDOFF HEX M8-1.25 X 25 X 30, 140L 1063 P08241063 PIVOT SHAFT SOCKET
1025 P08241025 LONGITUDINAL LEADSCREW 1064 P08241064 SET SCREW M5-.8 X 6
1026 P08241026 SLEEVE 1065 P08241065 PIVOT SHAFT
1027 P08241027 THRUST BEARING 8102 1066 P08241066 KNURLED KNOB M8-1.25, 16 X 25
1028 P08241028 THRUST BEARING 8104 1067 P08241067 SPIDER SAFETY GUARD
1029 P08241029 HOUSING 1068 P08241068 THREADED RECEIVER M16-2 X 40
1030 P08241030 BEARING COVER 1069 P08241069 HEX NUT M16-2
