Model G0824 (Mfd. Since 12/16)
-93-
Headstock Case & Shift Parts
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P08240001 CAP SCREW M6-1 X 20 25 P08240025 SET SCREW M8-1.25 X 8
2 P08240002 HEADSTOCK COVER 26 P08240026 COMPRESSION SPRING 18 X 6 X 1.2
3 P08240003 HEADSTOCK COVER GASKET 27 P08240027 STEEL BALL 6MM
4 P08240004 ROLL PIN 6 X 30 28 P08240028 FEED DIRECTION DIAL 50MM D
5 P08240005 O-RING 14 X 2.4 29 P08240029 RIVET 3.5 X 13MM NAMEPLATE
6 P08240006 SET SCREW M6-1 X 8 30 P08240030 HEADSTOCK CONTROL PANEL PLATE
7 P08240007 SHIFT SHAFT 32 P08240032 ROLL PIN 8 X 35
8 P08240008 SHIFT LEVER 33 P08240033 HEADSTOCK CONTROL PANEL FRAME
9 P08240009 SHIFT LEVER BLOCK 34 P08240034 GEAR 57T
10 P08240010 HEADSTOCK CASTING 35 P08240035 LOCK COLLAR
11 P08240011 OIL PLUG ZG 3/8" NPT 36 P08240036 SET SCREW M6-1 X 8 CONE PT
12 P08240012 LOCK WASHER 10MM 37 P08240037 SET SCREW M6-1 X 6
13 P08240013 HEX BOLT M10-1.5 X 18, 36L, EXT HEAD 38 P08240038 SPEED CONTROL LEVER
14 P08240014 CAP SCREW M10-1.5 X 30 39 P08240039 FLAT HD SCR M6-1 X 16
15 P08240015 FEED DIRECTION SHAFT BRACKET 42 P08240042 SPEED CONTROL LEVER SLEEVE
16 P08240016 CAP SCREW M6-1 X 25 43 P08240043 COLLAR
17 P08240017 SHIFT LEVER 45 P08240045 SPEED RANGE SHAFT
18 P08240018 SHIFT BLOCK 46 P08240046 SPINDLE SPEED SHAFT
19 P08240019 O-RING 25 X 2.4 47 P08240047 KEY 6 X 6 X 18 RE
20 P08240020 ROLL PIN 4 X 20 48 P08240048 SHIFT COLLAR
21 P08240021 FEED DIRECTION SHAFT 49 P08240049 SET SCREW M6-1 X 10 CUP-PT
22 P08240022 FEED DIRECTION DIAL COLLAR 50 P08240050 SHIFT FORK
23 P08240023 FLAT HD SCR M4-.7 X 10 51 P08240051 GEAR SHAFT 19T
24 P08240024 KEY 4 X 6 X 14 RE
