Model G0824 (Mfd. Since 12/16)
-95-
Headstock Drive Parts
REF PART # DESCRIPTION REF PART # DESCRIPTION
52 P08240052 SPINDLE PULLEY 74 P08240074 GEAR 38T
53 P08240053 ROCKER 75 P08240075 EXT RETAINING RING 35MM
54 P08240054 ROLL PIN 5 X 25 76 P08240076 BALL BEARING 6203ZZ
55 P08240055 ANCHOR PIN 77 P08240077 FRONT END COVER C
56 P08240056 ROCKER SHAFT 78 P08240078 SET SCREW M8-1.25 X 16 DOG-PT
57 P08240057 EXT RETAINING RING 8MM 79 P08240079 O-RING 40 X 3.1
58 P08240058 CAP SCREW M8-1.25 X 15 80 P08240080 CAP SCREW M4-.7 X 12
59 P08240059 FENDER WASHER 8MM 81 P08240081 BEARING COVER
60 P08240060 CAP SCREW M6-1 X 16 82 P08240082 BEARING COVER GASKET
61 P08240061 EXT RETAINING RING 8MM 83 P08240083 BALL BEARING 6204ZZ
62 P08240062 SHAFT 84 P08240084 SPACER 20 X 32 X 8
63 P08240063 GEAR SHAFT END COVER 85 P08240085 KEY 8 X 8 X 55 RE
64 P08240064 BEARING COVER GASKET 86 P08240086 GEAR SHAFT B
65 P08240065 OIL SEAL SD25 X 40 X 10 87 P08240087 GEAR 51T
66 P08240066 BALL BEARING 6005ZZ 88 P08240088 GEAR 43T
67 P08240067 KEY 8 X 8 X 32 RE 89 P08240089 SPACER
68 P08240068 GEAR SHAFT C 90 P08240090 GEAR 26T
69 P08240069 KEY 6 X 6 X 120 91 P08240091 GEAR 34T
70 P08240070 KEY 5 X 5 X 50 92 P08240092 GEAR 53T
71 P08240071 TOOTHED COLLAR GEAR 93 P08240093 O-RING 47 X 3.1
72 P08240072 GEAR 29T 94 P08240094 FRONT END COVER B
73 P08240073 GEAR 46T
