Model G0824 (Mfd. Since 12/16)
-97-
Headstock Spindle Parts
REF PART # DESCRIPTION REF PART # DESCRIPTION
95 P08240095 SPANNER NUT M65-2 116 P08240116 BALL BEARING 16004ZZ
96 P08240096 COLLAR 117 P08240117 GEAR 30T
97 P08240097 SET SCREW M6-1 X 25 DOG-PT 118 P08240118 EXT RETAINING RING 20MM
98 P08240098 OUTBOARD SPINDLE COVER 119 P08240119 HEX NUT M12-1.75
99 P08240099 OUTBOARD SPINDLE GASKET 120 P08240120 SHOULDER WASHER 12 X 25 X 4
100 P08240100 TAPERED ROLLER BEARING 32013 P5 121 P08240121 GEAR 40T
101 P08240101 EXT RETAINING RING 65MM 122 P08240122 OIL SEAL
102 P08240102 GEAR 37T 123 P08240123 GEAR SHAFT E
103 P08240103 GEAR 37T 124 P08240124 KEY 5 X 5 X 18 RE
104 P08240104 KEY 8 X 8 X 18 125 P08240125 ROLL PIN 3 X 10
105 P08240105 GEAR 74T 126 P08240126 KEY 6 X 6 X 50 RE
106 P08240106 EXT RETAINING RING 82MM 127 P08240127 SPACER
107 P08240107 TAPERED ROLLER BEARING 32015 P5 128 P08240128 FLANGE HUB
108 P08240108 GASKET 129 P08240129 SPACER
109 P08240109 FRONT SPINDLE COVER 130 P08240130 CAP SCREW M5-.8 X 16
110 P08240110 SPINDLE 131 P08240131 GASKET
111 P08240111 KEY 6 X 6 X 40 RE 132 P08240132 SPACER
112 P08240112 KEY 8 X 8 X 84 RE 133 P08240133 GEAR 37T
113 P08240113 O-RING 25 X 2.4 134 P08240134 EXT RETAINING RING 20MM
114 P08240114 SHAFT D 135 P08240135 SPIDER SCREW M10-1.5 X 35
115 P08240115 INT RETAINING RING 42MM 136 P08240136 HEX NUT M10-1.5
