GSi TYMPSTAR PRO - Acoustic Reflex Latency Test (ARLT); ARLT Screen Overview

GSI TympStar Pro User Manual
D-0129427 Rev. B Page 69 of 162
Zoom
The Zoom menu option displays the zoom dialog. The zoom dialog provides a
magnified view of the reflex decay data and displays the time and admittance
values for the selected point. The dialog has selections to scroll the waveform
and change the magnification.
Store
The Store menu option saves the selected reflex graph. The graph is copied from
the collection area to the stored display area. Only a single reflex decay per
stimulus may be stored. If you try to store a new reflex decay when a similar
reflex decay has already been stored, you will be prompted with a confirmation dialog
before the data is replaced.
Settings
The Settings menu option may be used to define the parameters used to collect
the reflex decay. A Settings dialog is presented with the reflex decay parameters
that are available. The reflex decay default settings are defined in the PC Config
App.
