GUDEL FlexxPump4 D - Zinc Plated Screws; Tab. 13-1 Torque Table for Zinc-Plated Screws Lubricated with Molykote (Mos2) Grease

13.1.1 Zinc plated screws
Unless otherwise specified, the following tightening torques apply for zinc-
plated screws lubricated with Molykote (MoS2) grease or secured with Loc-
tite 243:
Thread size Tightening torque [Nm]
8.8 10.9 12.9
M3 1.1 1.58 1.9
M4 2.6 3.9 4.5
M5 5.2 7.6 8.9
M6 9 13.2 15.4
M8 21.6 31.8 37.2
M10 43 63 73
M12 73 108 126
M14 117 172 201
M16 180 264 309
M20 363 517 605
M22 495 704 824
M24 625 890 1041
M27 915 1304 1526
M30 1246 1775 2077
M36 2164 3082 3607
Tab.13-1 Torque table for zinc-plated screws lubricated with Molykote (MoS2) grease
