GUDEL FlexxPump4 D - Fig. 4 -2 Detailed Design of Flexxpump4 D

4.1.1 Detailed design of FlexxPump4D
The product consists of the following components:
A
B
C
D
E
F
Fig.4-2 Detailed design of FlexxPump4D
A Covering D Casing
B Lubricant cartridge E Connection plug for supply and control
system
C Union ring F Hydraulic output
