PIN Assignment Color
1 Input voltage 24VDC brown
2 Input signal of the CLS white
3 Ground (GND), 0V blue
4 Output signal to the CLS black
Tab.5-1 Connector pin assignment
Connect the product as follows:
Prerequisite: The hydraulics is connected
1 Connect the PLC connecting cable to the connection plug
The product is connected
5.5 Actuate
The document "Requirements to the Lubrication Control of the FlexxPump4
D424A / 404DLS" provides detailed, non-binding recommendations from
Güdel for integration into the overall system. The document can be found in
the download area of our company website http://www.gudel.com.
Güdel provides software modules for the standard control systems without
obligation. The software modules can be found in the download area of our
company website http://www.gudel.com
Commissioning OPERATING MANUAL Lubrication system FlexxPump4D
9007202674126091_v2.0_EN-US
44
