FlexxPump4 D 6-
fold
Lubrication system with 6 lubrication points
D003080
A B C D
G F E
Fig.7-9 Design FlexxPump4 D 6-fold
A Lubricating pinion (not included in the
scope of delivery)
E 2. Axis (not included in the scope of de-
livery)
B Lubricating element (not included in the
scope of delivery)
F Lubrication line hose diameter of
6/3mm
C FlexxPump4D G 1. Axis (not included in the scope of de-
livery)
D Splitter
