GUDEL FlexxPump4 D - Fig. 4 -4 Function: Splitter, 3-Fold; Fig. 4 -5 Function: Y-Segment

Lubricant quantity
⅓ lubricant quantity
⅓ lubricant quantity
⅓ lubricant quantity
Fig.4-4 Function: Splitter, 3-fold
4.2.4 Y-segment
The quantity of the lubricant at the inputs is combined at the output. The Y-
segment only works in the direction of the arrow.
2x: lubrication quantity
Lubricant quantity
Lubricant quantity
Fig.4-5 Function: Y-segment
