CONFIGURATION
113
Segments Display
Run/Stop Indicator
Progress Indicator
Progress Indicator
Indicates the number of
segments that have to been
captured relative to the set
number of segments.
Run/Stop Indicator
Stop: The segments have finished
acquiring or have been stopped.
Run: The scope is ready to acquire
segments.
