GW Instek GDS-2000A Series User Manual

QUICK REFERENCE
61
Default Settings
The default factory installed settings can be
recalled at any time by pressing the Default key.
Default
Acquire
Mode: Sample
XY: OFF
Interpolation: Sin(x)/x
Sample rate: 2GSPS
Record Length: Auto
Display
Mode: Vector
Persistence: 240ms
Waveform intensity: 50%
Graticule intensity: 50%
Waveform visuals: Gray
Graticule: full
Channel
Scale: 100mV/Div
CH1: On
Coupling: DC
Impedance: 1MΩ
Invert: Off
Bandwidth: full
Expand: By ground
Position: 0.00V
Probe: voltage
Probe attenuation: 1x
Deskew: 0s
Cursor
Horizontal cursor: Off
Vertical Cursor: Off
Measure
Source: CH1
Gating: Screen
Display: Off
High-Low: Auto
Statistics: Off
Mean & Std Dev
Samples: 2
Horizontal
Scale: 10us/Div
Position: 0.000s
Math
Source1: CH1
Operator: +
Source2: CH2
Position: 0.00 Div
Unit/Div: 200mV
Math Off
Test
App: Go-NoGo
Trigger
Type: Edge
Source: CH1
