GW Instek GDS-2000A Series User Manual

SAVE/RECALL
195
Save
File Type/Source/Destination
Item
Source
Destination
Panel Setup
(DSxxxx.set)
 Front panel
settings
 Internal memory: Set1 ~
Set20
 File system: Disk, USB
Waveform Data
(DSxxxx.csv)
(DSxxxx.lsf)
(CH1~CH4.lsf,
Ref1~Ref4.lsf,
Math.lsf)*
ALLxxxx.csv
 Channel 1 ~ 4
 Math operation
result
 Reference
waveform Ref1~4
 D0~D15
1
 All displayed
waveforms
 Internal memory:
Reference waveform
Ref1~4, Wave1 ~ Wave20
 File system: Disk, USB
Display Image
(DSxxxx.bmp/png)
(Axxx1.bmp/png)**
 Display image
 File system: Disk, USB
*Stored in ALLXXX directories when All Displayed waveforms are
saved.
**Stored in ALLXXX directories when the Hardcopy key is assigned
to save Waveform, Setup or All.
1
Digital channels. Only applicable with the Logic Analyzer option.
