GW Instek GDS-2000A Series User Manual

CONFIGURATION
123
Segment Info
Operation
1. Press Analyze Segments from the
bottom menu.
Note: This key will only be
available in the Stop mode.
2. Press Segments Info.
3. A table showing all general setting information
for the segmented memory acquisitions is
shown on the display.
Info:
Sample rate, Record length,
Horizontal, Vertical
