Page #229 background image
REMOTE CONTROL CONFIG
229
Configure GPIB
Note
To use GPIB, the optional module, DS2-GPIB, must be
installed. Please see page 30 for installation details.
Connection
1. Connect a GPIB cable from a PC to the installed
GPIB module.
Configure GPIB
2. Press the Utility key.
Utility
3. Press I/O from the bottom menu.
4. Use the Variable knob to set the
GPIB Address from the side menu.
This option will only be available
when the GPIB module is installed.
Range
1 ~ 30
GPIB Constraints
Maximum 15 devices altogether, 20m cable
length, 2m between each device
Unique address assigned to each device
At least 2/3 of the devices turned On
No loop or parallel connection
