GW Instek GDS-2000A Series User Manual

GETTING STARTED
13
Interface
 USB host port: front and rear panel, for storage
devices.
 USB device port: rear panel, for remote control
or printing.
 Demo output
 GPIB (optional)
 RS232 port.
 Calibration output
 SVGA output and Ethernet port (optional)
Accessories
Standard
Accessories
Part number
Description
82DS-2304AM01
Quick Start Guide
N/A region dependent
Power cord
GTP-070A-4, for
GDS-2072A/GDS-2074A
Passive probe; 70 MHz
GTP-150A-2, for
GDS-2102A/GDS-2104A
Passive probe; 150 MHz
GTP-250A-2 for,
GDS-2202A/GDS-2204A
Passive probe; 250 MHz
GTP-350A-2 for,
GDS-2302A/GDS-2304A
Passive probe; 350 MHz
Options
Option
Number
Description
DS2-LAN
Ethernet & SVGA output
DS2-GPIB
GPIB Interface
DS2-FGN
DDS Function Generator
DS2-8LA
8-Channel Logic Analyzer card
(GLA-08)with 8-Channel Logic
Analyzer Probe (GTL-08LA)
