GDS-2000A Series User Manual
14
DS2-16LA
16-Channel Logic Analyzer card
(GLA-16)with 16-Channel Logic
Analyzer Probe (GTL-16A)
Optional
Accessories
Part number
Description
GTC-001
Instrument cart, 470(W)x430(D)mm
(U.S. type input socket)
GTC-002
Instrument cart, 330(W)x430(D)mm
(U.S. type input socket)
GTL-110
test lead, BNC to BNC heads
GTL-232
RS-232C cable, 9-pin Female to 9-pin
female, Null modem for computer
GTL-242
USB cable, USB2.0A-B type cable 4P
GTL-08LA
8-Channel Logic Analyzer Testing
Probe
GTL-16LA
16-Channel Logic Analyzer Testing
Probe
GLA-08
8-Channel Logic Analyzer Card
GLA-16
16-Channel Logic Analyzer Card
GTP-070A-4
Passive probe; 70 MHz
GTP-150A-2
Passive probe; 150 MHz
GTP-250A-2
Passive probe; 250 MHz
GTP-350A-2
Passive probe; 350 MHz
Drivers
USB driver
LabVIEW driver
