GDS-2000A Series User Manual
54
Trigger Pulse Runt Menu
Type
Pulse Runt
Source Polarity Mode Holdoff
Auto
Normal
EXT Probe
Volt
Current
When
>
<
=
10.0ns~10.0s
Threshold
Set to TTL
1.4V
Set to ECL
-1.3V
-XX~XXV
-XX~XXV
10.0ns~10.0s
Set to
Minimum
On
Off
Alternate
CH1~ CH4
1mX ~ 1kX
Attenuation
Trigger Rise & Fall Menu
Type
Rise & Fall
Source Mode Holdoff
Auto
Normal
When
>
<
=
10.0ns~10.0s
Threshold
Set to TTL
1.4V
Set to ECL
-1.3V
-XX~XXV
-XX~XXV
Slope
High
Low
10.0ns~10.0s
Set to
Minimum
EXT Probe
Volt
Current
On
Off
Alternate
CH1~ CH4
1mX ~ 1kX
Attenuation
Trigger Timeout Menu
Type
Timeout
Source Timer
10.0ns~10.0s
Trigger
When
EXT Probe
Volt
Current
CH1~ CH4,
D0~D15, AC
Line
1mX ~ 1kX
Attenuation
DC
AC
Off
HF
LF
Reject
On
Off
Noise Reject
Coupling
Stays High
Stays Low
Either
Level
-XX~XXV
Set to TTL
1.4V
Set to ECL
-1.3V
Set to 50%
Mode / Holdoff
Auto
Normal
Holdoff
10.00ns ~ 10.0s
Holdoff
Set to
Minimum
