GDS-2000A Series User Manual
206
*Only files in the current file path will be
available, this includes files saved in the
ALLXXX directories.
Allxxxx.csv files cannot be recalled to the
oscilloscope.
Only the “fast CSV” files can be recalled to the
oscilloscope.
6. Press To and select the reference
waveform to recall to.
To
Ref1~4
7. Press Recall Now to recall the
waveform.
USB File Utility
To edit USB flash drive contents
(create/ delete/ rename files and
folders) or to set the file path, press
File Utilities. For details, see page 211.
Recall Setup
Panel Operation
1. (For recalling from an
external USB flash drive)
Connect the drive to the
front or rear panel USB port.
Front
Rear
Host
