GW Instek GDS-2000A Series User Manual

GDS-2000A Series User Manual
118
Segment Measurement
Background
The Segmented memory function can be used in
conjunction with the automatic measurements in
the Measurement menu. Please note that digital
channels are not supported for measurement using
segments.
Display All
The Display All function will show all
the acquired segments
simultaneously.
Segments
Measure
This function will either perform
statistics calculations on the
segments or tabulate a list of the
measurement results.
Segments
Info
Provides configuration information
common for all the acquired memory
segments.
Display All
Operation
1. Press Analyze Segments from the
bottom menu.
Note: This key will only be
available in the Stop mode.
2. Press Display All
