CONFIGURATION
117
3. The position in time of the selected
segment relative to the time of the
first segment is shown in the
Segments Time key.
Play Through Each Segment
Background
When the all the segments have been acquired, the
play/pause key can be used to play back through
each segment.
Operation
1. Make sure the scope is Segments Stop mode. See
page 114 for details.
2. Press the Play/Pause key to run
through the acquired segments in
numerical order.
Press the Play/Pause key again
to pause the playback.
When the scope has played
through to the last segment,
pressing the Play/Pause key
again will play through each
segment again in reverse order.
