GW Instek GDS-2000A Series User Manual

GETTING STARTED
25
RS232 Port
Used for RS-232-based remote
control.
Module Slots
The module slots are used to install the optional
modules:
DS2-LAN: Ethernet and SVGA
DS2-GPIB: GPIB
GLA-08: 8 channel logic analyzer
GLA-16: 16 channel logic analyzer
Power Input
Socket
Power cord socket accepts AC
mains, 100 ~ 240V, 50/60Hz.
For power up sequence, see page
32.
Security Slot
Kensington security slot
compatible.
Ground Strap
Connector
For use with a grounding strap.
Go-No Go
Output
Outputs Go-No Go test results
(page 177) as a 500us pulse signal.
