GW Instek GDS-2000A Series User Manual

APPENDIX
255
GTP-250A-2
Applicable to: GDS-2202A & GDS-2204A
Position X10
Attenuation Ratio
10:1
Bandwidth
DC to 250MHz
Rise Time
1.4nS
Input Resistance
10MΩ when used with oscilloscopes
with 1MΩ input.
Input Capacitance
Approximately 17pF
Compensation Range
10 to 35pF
Max. Input Voltage
Position X1
Attenuation Ratio
1:1
Bandwidth
DC to 6MHz
Rise Time
58nS
Input Resistance
1MΩ (Oscilloscope Input)
Input Capacitance
47pF plus oscilloscope capacitance
Max. Input Voltage
300V CAT I, 150V CAT II (DC + peak
AC) derating with frequency.
Safety
EN61010-031 CAT II
GTP-350A-2
Applicable to: GDS-2302A & GDS-2304A
Position X10
Attenuation Ratio
10:1
Bandwidth
DC to 350MHz
Rise Time
1.0nS
Input Resistance
10MΩ when used with oscilloscopes
with 1MΩ input.
Input Capacitance
Approximately 13pF
Compensation Range
10 to 25pF
Max. Input Voltage
Position X1
Attenuation Ratio
1:1
Bandwidth
DC to 6MHz
Rise Time
58nS
Input Resistance
1MΩ (Oscilloscope Input)
Input Capacitance
46pF plus oscilloscope capacitance
Max. Input Voltage
300V CAT I, 150V CAT II (DC + peak
AC) derating with frequency.
Safety
EN61010-031 CAT II
500V CAT I, 300Vrms CAT II derating
with frequency.
500V CAT I, 300Vrms CAT II derating
with frequency.
