Hardi HC6500 User Manual

12 - Fault finding
12.3
10 10 Alarm Track Rear sensor failure The alarm is generated, if the sensor signal is less
than 0.5V or exceeds 4.5V.
SafeTrack shifted to manual.
Auto and Align is disabled.
Track Rear sensor failure.
Automatic tracking is aborted until the system has
been rebooted.
If “Align” mode is selected no movement takes
place, but trapeze is attempted locked.
Manual tracking still possible.
11 11 Alarm Agitation valve fault Error detection on.
AutoAgitation valve in self test and during spray
work.
Agitation valve fault. Motor disconnected. Motor
short circuit or blocked. Sensor failing.
12 12 Alarm Fill valve fault Error detection on Fill valve in self test.
On fault following occurs:
AutoWash allowed.
AutoFill disabled.
Fill valve fault. Motor disconnected. Motor short
circuit or blocked. Sensor failing.
13 13 Alarm Fluid system fault When suction SmartValve is on other port than
RinseTank and RinseTank flow exceed 10 l/min.
On fault following occurs:
AutoWash disabled.
AutoFill disabled.
Illegal flow is detected in Sections line or in
RinseTank line.
14 14 Alarm No RinseTank flow Error detection.
On fault following occurs:
AutoWash disabled.
AutoFill allowed.
RinseTank empty or no rinse water flow due to
other reasons.
15 15 Alarm Pressure valve fault Error detection not active, proofed error detection
not used.
On fault following occurs:
AutoWash disabled.
AutoFill disabled.
PressureValve fault. Motor disconnected. Motor
short circuit or blocked. Sensor failing.
16 16 Alarm Regulation valve fault Error detection not active, proofed error detection
not used.
On fault following occurs:
AutoWash disabled
AutoFill allowed.
Regulation valve fault. Motor disconnected. Motor
short circuit or blocked. Sensor failing.
17 17 Alarm Suction valve fault Error detection not active, proofed error detection
not used.
On fault following occurs:
AutoWash disabled.
AutoFill disabled.
SuctionValve fault. Motor disconnected. Motor
short circuited or blocked. Sensor failing.
18 18 Alarm TankGauge fault When TankGauge is enabled and frequency is
below 50Hz.
AutoWash is disabled.
AutoFill is disabled.
TankGauge fault.
TankGauge frequency is detected below 50Hz.
19 19 Warning Software error Terminal Close hydraulic valves Turn off PTO to stop spray. Turn off power to stop
hydraulics.
20 20 Warning Software error JobCom Close hydraulic valves Turn off PTO to stop spray. Turn off power to stop
hydraulics.
21 21 Warning Software error Grip Close hydraulic valves Turn off PTO to stop spray. Turn off power to stop
hydraulics.
22 22 Warning Software error SetBox Close hydraulic valves Turn off PTO to stop spray. Turn off power to stop
hydraulics.
23 23 Warning Software error FluidBox Turn off PTO to stop spray. Turn off power to stop
hydraulics.
24 24 Warning CAN bus failing to JobCom Close hydraulic valves Turn off PTO to stop spray. Turn off power to stop
hydraulics.
25 25 Warning CAN bus failing to SetBox Close hydraulic valves Turn off PTO to stop spray. Turn off power to stop
hydraulics.
ID Pr Type Text at display detail Criteria for fault
Operations disabled
Full screen Help text
