PAGE 2.2 - 28 OPERATION MARK IV HD J2 TAMPER
REVISED 10 -2020 JUPITER II BULLETIN 5082505
2.2
2.2.8 Mode Select Panel
2.2.8.1 F1 Travel Mode Button / Panel - See Figures 2.2-17 and 2.2-18
1. Press the F1 Travel Mode Button on the Mode Select Panel or the F1 Key on
the Right Operator Keypad or computer keyboard to enable the Travel Mode
and display the Travel Mode Panel on the screen. When the Travel Mode
Panel is displayed, the machine is in the Travel Mode and all Work functions
are disabled. See Figure 2.2-5. The panel displays the following:
2. Important: When switching from the Work Mode to the Travel Mode, the Gear Select
Panel will also be displayed on the Travel Mode Screen. See Gear Select Panel.
(1) Forward Direction Button: Press the button to select and enable the machine’s
forward propel system. The indicator on the button will highlight yellow when
selected.
(2) Neutral Button: Press the button to select and disable the machine’s propel system.
The indicator on the button will highlight yellow when selected.
(3) Reverse Direction Button: Press the button to select and enable the machine’s
reverse propel system. The indicator on the button will highlight yellow when
selected.
(4) Front Brake Pressure Info Box - Earlier Models Only: The info box displays the
machine’s front axle service brake operating air pressure in PSI.
(5) Rear Brake Pressure Info Box - Earlier Models Only: The info box displays the
machine’s rear axle service brake operating air pressure in PSI.
(6) Gear Shift Slider: The slider indicates the motor stroke applied to the gearbox motors.
As the motor stroke is decrease for higher speeds, the green slider will increase to
the right.
(7) Front Axle Speed Info Box: The info box displays the machine’s front axle travel
speed in MPH. If the input used to determine the speed is faulty, the info box will
highlight red.
(8) Rear Axle Speed Info Box: The info box displays the machine’s rear axle travel speed
in MPH. If the input used to determine the speed is faulty, the info box will highlight
red.
(9) Travel Speed Info Box: The box displays the machine’s actual travel speed in MPH.
