HBM T10F User Manual

Torque flange versions
T10F A0608-14.0 HBM: public 13
3 Torque flange versions
In the case of option 2 “Electrical configuration", the
T10F torque flange exists in versions KF1, SF1 and SU2.
The difference between these versions lies in the
electrical inputs and outputs on the stator, the rotors are
the same for all the versions of a measuring range.
Alternatively, versions SF1 and SU2 can be equipped
with a speed measuring system.
SF1
Measured
quantity
Type
Energy supply
Output signal
Can be connected
to HBM
measurement
electronics
Excitation voltage
54 V
PP
/14 kHz;
square‐wave
Torque
KF1
Connection
cable
FrequencyFrequency
V1 ... V4
Excitation voltage
generator in HBM
electronics
T10F
SU2
Supply voltage 18 V to 30 V DC
Separated extra‐low voltage (SELV circuit)
Excitation voltage generator in the torque flange
V5, V6, W1, W2
Frequency and
voltage
Torque and speed (option)
Fig. 3.1 T10F versions
You can find out which version you have from the stator
identification plate. The version is specified in the
“T10F-..." number there.
Example: T10F-001R-SU2-S-0-V1-Y (see also page 68).
