Mechanical installation
24 A0608-14.0 HBM: public T10F
6.4 Mounting the rotor
Important
For correct operation, comply with the mounting
dimensions (particularly the area free of metal, see
page 66).
Additional installation notes for the speed measuring
system can be found in chapter 6.7, page 33.
Important
Usually the rotor identification plate is no longer visible
after installation. This is why we include with the rotor
additional stickers with the important ratings, which you
can attach to the stator or any other relevant test‐bench
components. You can then refer to them whenever there
is anything you wish to know, such as the calibration
signal.
1. Prior to installation, clean the plane surfaces of the
measurement flanges and counter flanges. For safe
torque transfer, the surfaces must be clean and free
from grease. Use a piece of cloth or paper soaked in
solvent. When cleaning, make sure that you do not
damage the transmitter coils.
