HBM T10F User Manual

Specifications
70 A0608-14.0 HBM: public T10F
14 Specifications
Type T10F
Accuracy class 0.1
Torque measuring system
Nominal (rated) torque
M
nom
NVm 50 100 200 500 1k 2k 3k 5k 10k
Nominal (rated) sensitivity
(nominal (rated) signal range
between torque = zero and
nominal (rated) torque)
Frequency output kHz 5
Voltage output V 10
Sensitivity tolerance
(deviation of actual output
quantity at M
nom
from
nominal (rated) signal range)
Frequency output
%
"0.1
Voltage output %
"0.2
Output signal at torque =
zero
Frequency output kHz 10
Voltage output V 0
Nominal output signal
Frequency output
at positive nominal (rated)
torque kHz 15 (5 V symmetrical
1)
/12 V asymmetrical
2)
)
at negative nominal (rated)
torque kHz 5 (5 V symmetrical
1)
/12 V asymmetrical
2)
)
Voltage output
at positive nominal (rated)
torque V +10
at negative nominal (rated)
torque V ‐10
