Mechanical installation
34 A0608-14.0 HBM: public T10F
Mounting sequence
1. Push the slotted disc onto the adapter flange (or
additional flange) and align the screw holes.
2. Apply some screw locking device to the screw thread
and tighten the screws (tightening torque < 15 N⋅cm).
6.8 Aligning the stator
(speed measuring system)
The stator can be mounted in any position (for example,
“upside down" installation is possible). For perfect
measuring mode, the slotted disc of the speed measuring
system must rotate at a defined position in the sensor
pickup.
Axial alignment
There is a mark (orientation line) in the sensor pickup for
axial alignment (orientation line). When installed, the
slotted disc should be exactly above this orientation line.
Divergence of up to "2 mm is permissible in measuring
mode (total of static and dynamic shift).
