Order numbers, accessories
68 A0608-14.0 HBM: public T10F
13 Order numbers, accessories
Order number:
Ordering example:
YSF1 0500Q
Code Option 2: Electrical configuration
SF1
Output signal 10 kHz "5 kHz,
supply voltage 18 ... 30 V DC
SU2
Output signal 10 kHz "5 kHz and "10 V,
supply voltage 18 - 30 V DC
Code Option 6: Mounted couplings
MODULFLEX
4)
N Without coupling
With coupling
Code Option 3: Linearity deviation
including hysteresis
S < ±0.1
G < ±0.05
1
S
Code Option 5: Connection cable
V1 Torque connection cable for KF1,
423 free ends, 6m
V2
*)
Torque connection cable for KF1,
423 free ends, max. 80 m
V3 Torque connection cable for KF1,
423 MS3106PEMV, 6m
V4
*)
Torque connection cable for KF1,
423 MS3106PEMV, max. 80 m
V0 Without connection cable
Code Option 4: Speed measuring system
2)
1 360 Pulses/revolution
2 180 Pulses/revolution
3 90 Pulses/revolution
4 60 Pulses/revolution
5 30 Pulses/revolution
6 15 Pulses/revolution
7 720 Pulses/revolution
3
)
0 Without the speed measuring system
V5
m
5)
KF1
Output signal 10 kHz "5 kHz,
excitation voltage 14 kHz / 54 V; square wave
V5 Torque connection cable for
SF1/SU2, 423 DSub 15P, 6m
V6
*)
Torque conn. cable for SF1/SU2,
423 D-Sub 15P, max. 50 m
W1 Torque and speed, one cable each,
423 D‐Sub 15P, 6m
W2
*)
Torque and speed, one cable each,
423 D‐Sub 15P, max. 50 m
m
5)
Y
K−T10F −
K−T10F −
Code Option 1: Measuring range
100Q 100 N⋅m
200Q 200 N⋅m
500Q 500 N⋅m
001R 1 kN⋅m
002R 2 kN⋅m
003R 3 kN⋅m
005R 5 kN⋅m
050Q 50 N⋅m
010R 10 kN⋅m
1)
For voltage output <±0.07
2)
For option 2, code SF1, SU2 only
3)
Only with option 1, code 002R,
003R, 005R, 010R
4)
Specifications, see data sheet B0120‐x.x
5)
With selections V2, V4, V6 and W2, please
specify required length of cable.
