HBM T10F User Manual

Dimensions
T10F A0608-14.0 HBM: public 67
Mounting dimensions
Measuring
range
Dim. "m"
(mm)
Area free of metal parts
1)
(mm)
a x
50 N⋅m 16.25 20 29.5
100 N⋅m
200 N⋅m 21.75 20 29
500 N⋅m 30.25 20 29.5
1 kN⋅m 30.25 20 29.5
2 kN⋅m 31.25 25 29
3 kN⋅m 43.75 25 29
5 kN⋅m 49.75 35 29.5
10 kN⋅m 54.75 35 29.5
1)
Support with metal rod is permissible with the recommended
dimensions
