Specifications
82 A0608-14.0 HBM: public T10F
15.3 Additional mechanical data
Nominal (rated) torque
M
nom
NVm 50 100 200 500 1 k 2 k 3 k 5 k 10 k
Mechanical values
Stiffness in the axial
direction c
a
kN/mm 90 90 190 410 430 500 900 1200 2100
Stiffness in the radial
direction c
r
kN/mm 200 200 280 430 440 750 820 1000 1430
Stiffness during the
bending moment
around a radial axis c
b
kN⋅m/
deg.
0.9 0.9 2.7 8.8 9.1 18.3 37.5 69.0 142
kN⋅m/
rad
51 51 155 510 520 1050 2150 3950 8000
