Mechanical installation
28 A0608-14.0 HBM: public T10F
6.5 Mounting the stator
On delivery, the stator has already been installed and is
ready for operation. The antenna segments can be
separated from the stator, for example, for maintenance
or to facilitate stator mounting. To stop you modifying the
center alignment of the segment rings opposite the base
of the stator, we recommend that you separate only one
antenna segment from the stator.
If your application does not require the stator to be
dismantled, proceed as described in points 2., 6., 7.
and 8.
Version with speed measuring system
As the speed sensor includes the slotted disc, it is not
possible to move the stator axially over the
pre‐assembled rotor (exception: Measuring ranges
50 N⋅m, 100 N⋅m and 200 N⋅m).
In this case, you should also comply with chapter 6.7
“Fitting the slotted disc (speed measuring system)”,
page 33.
Important
Check the screw connections of the antenna segments
(see Fig. 6.5) both after initial installation and then at
regular intervals for correct fit and tighten them if
necessary.
