HBM T10F User Manual

Mechanical installation
T10F A0608-14.0 HBM: public 27
Nominal
(rated)
torque
(NVm)
Fastening
screws
(Z)
1)
Fastening
screws
Property class
Max. screw‐in depth
(Y) of screws in the
adapter flange
(mm)
Prescribed
tightening
torque
(NVm)
50 M6 10.9 7.5
2)
14
100
200 M8 11 34
500 M12 18 115
1 k M12 18 115
2 k M14 18 185
3 k M14 26 185
5 k M18 33.5 400
10 k M18 12.9
3)
33.5 470
1)
DIN EN ISO 4762; black/oiled/m
tot
= 0.125
2)
14 mm for speed module option; use 6 mm longer screws because of the intermediate flange.
3)
If property class 12.9 screws are not available, class 10.9 screws can also be used (tightening
torque 400 N⋅m). The permissible limit torque then reduces to 120% related to M
nom
.
Fig. 6.4 Fastening screws
