HBM T10F User Manual

Specifications
T10F A0608-14.0 HBM: public 71
Nominal (rated) torque
M
nom
10k5k3k2k1k50020010050NVm
Load resistance
Frequency output kΩ ≥2
Voltage output kΩ ≥5
Longterm drift over 48 h
Voltage output mV
≤"3
Measurement frequency
range
Voltage output Hz 0 ... 1000 (-3 dB)
Group delay
Frequency output ms 0.15
Voltage output ms 0.9
Residual ripple
Voltage output % 0.4 (peak‐to‐peak)
Temperature effect per 10
K in the nominal (rated)
temperature range
on the output signal, related
to the actual value of the
signal spread
Frequency output
%
<"0.1
Voltage output %
<"0.2
on the zero signal, related to
the nominal (rated)
sensitivity
Frequency output % <±0.1
<"0.05
Voltage output % <±0.2
<"0.15
Power supply (version
KF1)
Excitation voltage (square
wave) V
54"5% (peak‐to‐peak)
Calibration signal triggering
V
80"5 %
Frequency kHz approx. 14
Max. current consumption A 1 (peak‐to‐peak)
