Specifications
72 A0608-14.0 HBM: public T10F
Nominal (rated) torque
M
nom
10k5k3k2k1k50020010050NVm
Preamplifier excitation
voltage
V 0/0/+15
Preamplifier, max. current
consumption mA 0/0/+25
Power supply (version
SF1/SU2)
Nominal (rated) supply
voltage (separated extralow
voltage (SELV))
V (DC) 18 ... 30; asymmetrical
Current consumption in
measuring mode
A < 0.9
Current consumption in
startup mode
A < 2
Nominal (rated) power
consumption
W < 12
Linearity deviation
including hysteresis,
relative to the nominal
(rated) sensitivity
Frequency output
%
<"0.1 (optional <"0.05)
Voltage output %
<"0.1 (optional <"0.07)
Rel. standard deviation of
reproducibility
as per DIN 1319, relative to
the variation of the output
signal
%
<"0.03
Calibration signal approx. 50% of M
nom
;
more precise value on identification plate
Tolerance of the
calibration signal
%
<"0.05
Speed measuring system
Measurement system Optical, by means of infrared light and metallic slotted disc
Mechanical increments No. 360 720
Positional tolerance of the
increments
mm
"0.05
Slot width tolerance mm
"0.05
