HBM T10F User Manual

Specifications
T10F A0608-14.0 HBM: public 73
Nominal (rated) torque
M
nom
10k5k3k2k1k50020010050NVm
Pulses per revolution
adjustable
No.
360; 180; 90; 60; 30; 15 720; 360; 180; 90; 60;
30; 15
Output signal V 5 symmetrical (complementary signals RS-422)
2 square‐wave signals, approx. 90_ phase‐shifted
Load resistance kΩ ≥2
Minimum rotational speed
for sufficient pulse
stability
min
-1
2
Group delay μs < 5 typ. 2.2
Max. permissible axial
displacement of the rotor
to the stator mm
"2
Max. permissible radial
shift of the rotor to the
stator mm
"1
Hysteresis of reversal
3)
in the case of relative
vibrations between the rotor
and the stator
Torsional vibration of the
rotor
Degr. < approx. 2
Radial vibration
amplitude of the stator
mm < approx. 2
Permitted degree of
pollution, in the optical path
of the optical sensor (lenses,
slotted disc)
% < 50
Protection against
ambient light
By fork and infrared filter
