Structure and mode of operation
16 A0608-14.0 HBM: public T10F
Stator
Antenna segments
Rotor
Fan‐type lock
washers
Speed sensor (option)
Measuring
body
Adapter flange
(without slotted disc)
Housing
Fig. 5.1 Mechanical structure, exploded view
