Dimensions

T10F A0608-14.0 HBM: public 63

Measur

ing

range

Dimensions (in mm; 1 mm = 0.03937 inches)

4 Ø

B

L

Z

Ødza

Ød

Y X

50 N⋅m 15.5 17.5 25 31.5 7.5 29.5 117 87 100 11 131 75 75 6.4 M6 13

100 N⋅m 15.5 17.5 25 31.5 7.5 29.5 117 87 100 11 131 75 75 6.4 M6 13

200 N⋅m 17.5 17.5 30.5 30.5 11 29.5 137 105 121 14 151 90 90 8.4 M8 14

500 N⋅m 20.5 20.5 40.5 40.5 18 33 173 133 156 20 187 110 110 13 M12 15.5

1 kN⋅m 20.5 20.5 40.5 40.5 18 33 173 133 156 20 187 110 110 13 M12 15.5

2 kN⋅m 22.5 22.5 42.5 42.5 18 35 207 165 191 24 221 140 140 15 M14 16.5

3 kN⋅m 27.0 22.5 55 55 26 35 207 165 191 24 221 140 140 15 M14 18.8

5 kN⋅m 28.5 28.5 64 64 33.5 41 254 206 238 30 269 174 174 19 M18 19.5

10 kN⋅m 33.5 28.5 69 69 33.5 41 254 206 238 30 269 174 174 19 M18 22.5
