HBM T10F User Manual

Dimensions
T10F A0608-14.0 HBM: public 65
Measuring
range
Dimensions (in mm; 1 mm = 0.03937 inches)
b jd jD H1 H2 H3 h l
50 N⋅m 15.5 125 155 235 239 253 157.5 31.5
100 N⋅m 15.5 125 155 235 239 253 157.5 31.5
200 N⋅m 17.5 145 175 255 259 273 167.5 31.5
500 N⋅m 20.5 181 211 291 295 309 185.5 33.5
1 kN⋅m 20.5 181 211 291 295 309 185.5 33.5
2 kN⋅m 22.5 215 245 325 329 343 202.5 34.5
3 kN⋅m 22.5 215 245 325 329 343 202.5 34.5
5 kN⋅m 28.5 262 292 373 377 391 226.5 37.5
10 kN⋅m 28.5 262 292 373 377 391 226.5 37.5
